[V2L-DF] Vehicle to load adapter for Dongfeng EV

Description

Main features:

• Compact ALL-IN-A PLUG design
• Maximum output power up to 2.5 kW (depending on the socket outlet)
• V2L-DF, used in combination with Metron portable EV charger(s), can also charge any other electric car from your Dongfeng EV.
• All weather proof

Technical Specifications:

• Plug Type (EV Side): Type 2 (IEC 62196) Female Plug
• Socket outlet types (load side): Type G (UK) or Type F (EU)
• Maximum continuous output current: 13 A
• Max. output power (single phase): 3,7 kW
• Rated Voltage (single phase): 230 V
• Color: Black (for large quantities we offer any color according to request)
• UV resistant
• Operating Ambient Air Temperature Range: -40 °C to 50 °C (at full sun exposure)
• IP Rating: IP44
• Dimensions [max. diameter / length]: 70 mm / 280 mm
• Weight: 420 g
• IEC 61851 compliant
• CE approved
• Warranty: 3 years

---

DECLARATION OF CONFORMITY

---

Compatibility

Vehicle to load type adapter can work with Dongfeng electric vehicles only. It will NOT work on other electric vehicles.

Green production

All our products are produced in a carbon neutral way by using “Sustainable energy cycle” method. Production plant where we make charging cables and portable charging stations is the first fully sustainable production facility for EV charging cables. All energy, needed for the heating and cooling of the building, production process and for transportation of goods and employees (except deliveries of heavy materials by trucks), is produced by 2 photovoltaic power plants and stored in 4 storage batteries. Almost all of the raw materials we use (cables, plugs) are produced in EU, to shorten supply routes and support local economy. Buying our products helps developing sustainable economy.

DISCLAIMER:

Metron® is not affiliated with or endorsed by Dongfeng car brand. It is neither inferred nor implied that products sold by Metron® are authorized by or in any way connected to Dongfeng. All manufacturer names, symbols, and descriptions used in our images and text are used solely for identification purposes only.
